Electric Drum Transmission Mode X-Ray Baggage Scanner
Advanced security screening device providing maximum radiation leak below 0.3 μGyH and maximum leakage radiation under 0.1μGyH for superior safety and performance.
Product Overview
The SECUPLUS X-Ray Baggage Scanner is a state-of-the-art security screening device designed for efficient and reliable inspection of luggage and personal belongings. Engineered for stability and durability, this robust machine weighs approximately 120 kg and features solid construction for long-term operation with minimal maintenance.
With spacious tunnel dimensions measuring 1020 mm by 1313 mm, this scanner accommodates larger items and multiple bags simultaneously, increasing throughput and reducing waiting times in high-traffic environments.
Key Features
- Product Name: X-Ray Baggage Scanner
- Weight: Approximately 120 kg
- Software Interface: Multi-language Support
- Wire Resolution: <0.0787mm Metal Wire
- Operation System: Windows 10
- Purpose: Checkpoint Screening
- High precision detection for security screening
- Electric drum transmission mode
Technical Specifications
| Parameter |
Specification |
| Operation System |
Windows 10 |
| Penetration |
≥30mm Steel |
| Operation Power |
220V AC (±10%) 50Hz ±3Hz |
| Weight |
Approximately 120 kg |
| Gross Weight |
380 kg |
| Transmission Mode |
Electric Drum |
| Wire Resolution |
<0.0787mm Metal Wire |
| Software |
Multi-language Support |
| Purpose |
Checkpoint Screening |
Applications
The SECUPLUS SPX-3025P X-Ray Baggage Scanner is ideal for various security environments including:
- Airports, train stations, bus terminals, and seaports
- Government buildings, courthouses, and embassies
- Hotels, churches, and shopping malls
- Stadiums, concert halls, and conference centers
- Large event venues and public gatherings
Certified by CE and ISO9001, this scanner ensures maximum leakage radiation under 0.1μGy/H and maximum leak below 0.3 μGy/H, making it safe for continuous operation in diverse environments.
Customization Services
SECUPLUS offers customized solutions for the SPX-3025P X-Ray Baggage Scanner to meet specific security requirements. Each unit is packaged in sturdy wooden boxes for safe delivery, with flexible payment terms including L/C, T/T, and Western Union.
Frequently Asked Questions
What is the brand and model number of the X-Ray Baggage Scanner?
Manufactured by SECUPLUS, model number SPX-3025P.
Does the SECUPLUS SPX-3025P have any certifications?
Yes, certified with CE and ISO9001 certifications.
What is the minimum order quantity?
Minimum order quantity is 1 set.
What are the available payment terms?
Payment can be made via L/C (Letter of Credit), T/T (Telegraphic Transfer), or Western Union.
How is the product packaged for shipping?
Securely packaged in wooden boxes to ensure safe transportation.
What is the supply capacity?
Supply ability is 50 sets per month.
Is the price fixed?
No, the price is negotiable depending on order quantity and other factors.
